Application:
Suitable for welder of kettle, vacuum cup, stainless steel bowl, sensor, tungsten wire, high power diode(triode),aluminum alloy, laptop sheel, mobile phone battery, door handle, mould, electric apparatus fittings, filter, nozzle, stainless steel products, golf head, zinc alloy and so on.
artworks weld point straight line, circle, square or any plane graphs drawn by AUTOCAD.
Product Advantages:
1.Ceramic converging cavity is imported from the Britain. It is corrosion resistant and high temperature resistant ,and has 8-10 years service life.
2.High production efficiency and high welder speed, realizing automatic mass production on the production line
3.The laser head can be adjusted for 360 degree
4.The size of the light spots can be adjusted
5.The work bench can be moved in two dimensions
Application:
Suitable for welder of kettle, vacuum cup, stainless steel bowl, sensor, tungsten wire, high power diode(triode),aluminum alloy, laptop sheel, mobile phone battery, door handle, mould, electric apparatus fittings, filter, nozzle, stainless steel products, golf head, zinc alloy and so on.
artworks weld point straight line, circle, square or any plane graphs drawn by AUTOCAD.
Product Advantages:
1.Ceramic converging cavity is imported from the Britain. It is corrosion resistant and high temperature resistant ,and has 8-10 years service life.
2.High production efficiency and high welder speed, realizing automatic mass production on the production line
3.The laser head can be adjusted for 360 degree
4.The size of the light spots can be adjusted
5.The work bench can be moved in two dimensions
Model No | LS-WM200 | LS-WM300 | LS-WM400 | ||
Max. laser power | 200W | 300W | 400W | ||
Laser wave-length | 1064nm | ||||
Solder joint range | 0.1-3.0mm | ||||
Solder joint size | 0.2-3.0mm | ||||
Pulse width | ≤20ms | ||||
Pulse frequency | ≤50Hz | ||||
Mono pulse Max power | 100J/150J/200J | ||||
Type of Laser | Nd:YAG | ||||
Sighting positioning precision | RED light,CCD monitor system(optional) | ||||
Work bench stroke | 200×200mm - 1200×1200mm(optional) | ||||
Positioning accuracy | 0.02mm | ||||
RepeatablePositioning accuracy | ±0.01mm | ||||
Loading ability | ≤200KG | ||||
Power supply | 380V/3-phase/50Hz/40A | 380V/ 3-phase/50Hz/60A | 380V/ 3-phase/50Hz/60A | ||
Power system | 9KW | 12KW | 14 KW | ||
Cooling way | Water cooling |
Model No | LS-WM200 | LS-WM300 | LS-WM400 | ||
Max. laser power | 200W | 300W | 400W | ||
Laser wave-length | 1064nm | ||||
Solder joint range | 0.1-3.0mm | ||||
Solder joint size | 0.2-3.0mm | ||||
Pulse width | ≤20ms | ||||
Pulse frequency | ≤50Hz | ||||
Mono pulse Max power | 100J/150J/200J | ||||
Type of Laser | Nd:YAG | ||||
Sighting positioning precision | RED light,CCD monitor system(optional) | ||||
Work bench stroke | 200×200mm - 1200×1200mm(optional) | ||||
Positioning accuracy | 0.02mm | ||||
RepeatablePositioning accuracy | ±0.01mm | ||||
Loading ability | ≤200KG | ||||
Power supply | 380V/3-phase/50Hz/40A | 380V/ 3-phase/50Hz/60A | 380V/ 3-phase/50Hz/60A | ||
Power system | 9KW | 12KW | 14 KW | ||
Cooling way | Water cooling |
